Airmar PM111C-LH Low-High Chirp, 2kW, No Connector, DT

The PM111LH is a pocket/keel mounted, 2 kW transducer which delivers excellent target resolution, bottom discrimination, and bait and game-fish separation. The PM111LH is packed with a fifteen-element, low-frequency array that operates anywhere between 38 and 75 kHz, delivering great depth capability down to 1829 m (6000'). The single, high-frequency ceramic operates at any frequency between 130 and 210 kHz and has a narrow, 8 to 4, beam that provide tremendous bottom detail and fish-target discrimination at depths to 457 m (1500').

• Depth and fast-response water-temperature sensing
• 2 kW of power for excellent deep-water performance
• Low frequency: 38 to 75 kHz
• 19 to 10 port-starboard beamwidth
• 10 to 5 fore-aft beamwidth
• Maximum depth of 1829 m (6000')
• High frequency: 130 to 210 kHz
• 8 to 4 beamwidth
• Maximum depth of 457 m (1500')
• 117 kHz of total bandwidth from one transducer
• Covers popular fishing frequencies of 50, 60, and 200 kHz plus everything else in the bandwidth
• Curved-edge design for wet-box installation
• Designed for custom pocket, keel, or welded-tank mounting
• SEALCAST, seamless, urethane housing for long life underwater
• Also available as in-hull (R111LH) and thru-hull external (R109LH) mounts
• Patented Xducer ID technology
